Which Lithium Battery is Right for Your Golf Cart?

• Faster Charging: Charges up to 4 times faster than a lead acid battery of comparable voltage.
• More Operational Power: Lithium has a 40-50 mile range per charge, almost double traditional lead batteries.
• More Torque: An increase in torque provides faster responses to initial acceleration and increases climbing power in hilly terrain.
• Lightweight: Swapping batteries reduces your cart’s overall weight, as a single lithium battery weighs approximately 110lbs, while six lead batteries average 360-400lbs.
• Low Self-Discharge: Worry-free storage makes these batteries especially great for seasonal use.
• Longevity: Delivers up to 10 times more cycles than traditional lead batteries thanks to 8+ year design life.

Lithium batteries include the following:

• Remote Power Switch: On battery and remote power switch to extend battery life by disconnecting power when not in use. This can be mounted to the front panel of the cart for easy on/off management of the battery.
• High Current Output Capable: Up to 300A discharge current allows carts to tackle steep inclines effortlessly.
• Bluetooth Connectivity to BATTLite Battery Gauge: Battery gauge can connect, via Bluetooth, to the BATTLite app for digital monitoring and state of charge information. The gauge must be connected to the battery, and the battery must be in the on position to connect to the app. Download the app now to get additional information.

This Energizer Industrial Lithium battery is assembled using Grade A LiFePO4 cells. The IP67-rated case is lighter and more compact than traditional lead or other single packs, reducing the overall footprint in your cart.

The battery uses a software BMS with standard protection functions like cell balancing, overcharge, over-discharge, overcurrent, and low/high temperature. The BMS also handles more complex tasks like health monitoring, and analysis to optimize performance.

Important Lithium Safety Warnings and Warranty Details

• A Software Battery Management System (BMS) controls power to and from the battery pack to reduce the risk of overcurrent and overcharge.
• Lithium batteries are intended as replacements for deep cycle applications only; they are not for use as a cranking/starting battery.

IMPORTANT NOTE: If a cart requires conversion and utilizes any lighting, or sound accessories that operate on 12V power, a voltage reducer is required for safe operation.

Each lithium battery includes a 5-Year Limited Warranty. The warranty process may involve battery repair, or replacement credit, depending on the claim.

Older golf carts weren’t built with lithium batteries in mind. Fortunately, the conversion process is relatively easy. In addition to your new batteries, you’ll need:

• Lithium Compatible Charger: Lithium specific, this 48V 18A unit is compatible with the Energizer Industrial Lithium battery
• Brackets: These brackets are designed to properly fit and support the battery installation in the most common carts.
• AC Charge Port: These can be mounted directly on the cart to connect the charger to an AC outlet for convenient recharging between drives.

All of the above accessories are sold separately. In addition, we recommend using safety equipment like safety glasses, steel toe shoes, and gloves as part of your installation process. Depending on your exact cart make and model, you may also need cordless drill, drill bits or hole saw bits, screwdriver bits, torque wrench, socket extensions, pliers, zip ties, and electrical tape.

Trust your golf cart battery upgrade to the experts at Batteries Plus. Or use our How to Install Golf Cart Batteries guide, written by our experts, to learn what you need to get the job done yourself.

Many Batteries Plus locations offer professional battery conversion and installation services, helping ensure you get the right lithium charger, proper mounting bracket, and a seamless setup for long-term performance. Check with your local Batteries Plus store for available services and expert support.
